Samsung DM65E-BR - DME-BR Series 65" Slim Direct-Lit LED E-Board Display
The large 65" display includes a pre-assembled touch overlay.
This product is no longer available, please contact us for a replacement.
Samsung's DM65E-BR is a ready-to-use, all-in-one E-Board display solution. The large 65" display includes a pre-assembled touch overlay. The embedded System-on-Chip (SoC) media player and E-Board software makes it portable, flexible and easy to set up. And with a full range of connectivity options, including Wi-Fi® for seamless connection to mobile devices, you can meet your organization's specific presentation needs.
- Large 65" screen to maximize readability in meeting rooms or classrooms for corporate and educational organizations
- Included factory-assembled touch overlay enables interactivity and is easy to install
- All-in-one, PC-less solution with an embedded media player and E-Board software application
- Optional MagicIWB I2 presentation solution can be added via select PIM modules for advanced E-Board functionality
Large E-Board for Corporate and Educational Organizations
This all-in-one E-Board display solution provides portability and flexibility while minimizing set-up time in meeting rooms or classrooms. The large 65" screen maximizes readability to facilitate smooth and informative presentations.
Included, Pre-Assembled Touch Overlay
The DM65E-BR comes with a pre-assembled touch overlay to transform your display into an interactive whiteboard with up to 10 simultaneous touchpoints and dual drawing capability. The factory assembly means it takes less time to install, so you can get right to creating more collaborative and dynamic presentations.
Along with the display itself and included touch overlay, this E-Board solution features an embedded System-on-Chip (SoC) media player for a PC-less touch solution. Also included is an E-Board software application. With all of this right out of the box, you'll enjoy portability, flexibility and a simple setup.
Optional Samsung MagicIWB I2 Software
The optional MagicIWB I2 solution can transform a traditional presentation into a dynamic educational experience with on-screen note-taking functionality, video and image capture capability. So you can deliver rich content and interactivity in your meeting rooms or classrooms.
Enhanced System-on-Chip Performance with a Quad Core CPU
Powered by a System-on-Chip (SoC) semiconductor and quad core CPU with 8GB of storage, Samsung's SMART Signage Platform is an open and integrated player side media platform that provides a powerful, streamlined solution to reduce TCO for digital signage deployments, through savings in hardware, installation and operating costs.
Full Range of Connectivity Options Including Wi-Fi®
Versatile connectivity options include USB 2.0, HDMI, RJ45, RS232C, Wi-Fi® and more. With Wi-Fi®, enjoy seamless connectivity to mobile devices, for easy media sharing and screen control to simple content mirroring from a tablet or mobile phone to your display.
Slim Direct-Lit LED Technology
Achieve sharp, detail-rich images and crisp, legible type with this slim direct-lit display featuring 1920 x 1080 Full HD resolution. While LED technology reduces power consumption and heat output.
|Samsung DM65E-BR - DME-BR Series 65" Slim Direct-Lit LED E-Board Display Specifications|
|Brightness||380nit (with touch glass)|
|Panel Technology||120Hz D-LED BLU|
|Contrast Ratio (Typical)||4000:1|
|Contrast Ratio (Dynamic)||50,000:1|
|Viewing Angle (H/V)||178:178|
|Input||RGB - Analog D-SUB, DVI-D, Display Port 1.2, VIDEO - Rear: HDMI1, HDMI2, Front Tray Box: HDMI3 Component(CVBS Common), AUDIO - Stereo mini Jack, USB - Rear: USB 2.0 X 1, Touch in X 1, Front Tray Box: USB 2.0 X 2, Touch out (USB Upstream)|
|Output||AUDIO - Stereo mini Jack|
|External Control||RS232C(in/out) thru stereo jack, RJ45|
|Sensor||IR, Ambient Light|
|Power Supply||AC 100 - 240 V~ (+/- 10 %), 50/60 Hz|
|Power Consumption (Typical/Max)||200W/h / 264W/h|
|Power Consumption (Standby)||<0.5W|
|Special||H/W: Super Clear Coating, Temperature Sensor, Clock Battery(80hrs Clock Keeping), Built in Speaker(10W x 2), WiFi Module Embedded, Front Tray Box, S/W: Magic Clone(to USB), Auto Source Switching & Recovery, RS232C/RJ45 MDC,Plug and Play, PIP/PBP, Image Rotation, Button Lock, Built In MagicInfo Player S3, MagicIWB S2, Magic Presenter, USB Auto Switching, Firmware Update by Network, LFD New Home Screen, Predefined Template for Vertical Usage, Multi Channel, Mobile Control, Event Schedule, Backup Player|
|Built-in Speakers||Built in Speaker(10W + 10W)|
|Without Stand (W x H X D)||60.4" x 35.8" x 3"|
|Packaging (W x H X D)||65.6" x 40.9" x 9.8"|
|Product Weight||101.6 lb.|
|Package Weight||119.3 lb.|
|Included in Box|
|Included in Box||Quick Setup Guide, Regulayory Guide, Warranty Card, Power Cord, Remote Controller, Batteries, RS232C(IN) adapter, Pen 1, Pen Tray|
|Optional Wall Mount Kit||WMN4675MD, WMN4277SD, WMN6575SD|
|Optional Media Player||Embbeded, SBB(Attachable), PIM(Attachable)|
|Operating Temperature||0℃~ 40℃|
