Samsung 55" 890 Series Edge-Lit Ultra-Thin LED Hospitality TV
Smart TV 2.0 with advanced management. Premium in every way.

Samsung 55" 890 Series Edge-Lit Ultra-Thin LED Hospitality TV

Samsung Products
Samsung Hospitality TVs
55" 890 Series Edge-Lit Ultra-Thin LED Hospitality TV
#HG55NB890XFXZA
Please Call for Pricing!

More pricing below, click here!

Overview:

Samsung's 890 Series Hospitality TVs combine superior picture quality and enhanced energy efficiency in a sleek form factor to allow the ultimate in-room guest experience. Samsung LYNK™ provides access to premium content while facilitating ease of operations. And edge-lit, ultra-thin LED technology offers world-class performance on the 55" display. Immerse your guests in the future of hospitality.

  • Premium Edge-Lit Ultra-Thin LED Technology
  • Smart TV 2.0
  • Samsung LYNK™ SINC Interactive Content Management System
  • Samsung LYNK REACH 2.0 Content Management Solution

Features

Premium Edge-Lit Ultra-thin LED Technology

Edge-lit LED technology provides the brilliance and energy savings advantages of LED technology, along with the uniform brightness typical of CCFL displays. And it does it all with an efficiency that makes it a more affordable technology. In fact, it’s possible to upgrade your rooms to LED technology for a cost comparable to CCFL technology.

Smart TV 2.0>

Experience the next generation of our ground-breaking TVs with Smart Interaction, full web browsers, all-new content, all-new content services, faster processors and much more.

Samsung LYNK™ SINC Interactive Content Management System

This IP-based content management solution delivers enhanced HTML and rich text with protocols to communicate between Samsung Interactive TVs and hotel property management software. Facility managers can completely customize the in-room entertainment by unlocking rich content from the Samsung Hospitality Widget Library (Facebook, Twitter, AccuWeather, Google Maps™).

Samsung LYNK REACH 2.0 Content Management Solution

The Samsung REACH 2.0 (Remote Enhanced Active Control for Hotels) Management Solution is used in conjunction with an existing coaxialbased infrastructure. It provides centralized TV controls, basic static content management capabilities and an Interactive Program Guide (IPG). Property management will be able to easily update and change information using a Windows®-based system.

H-Browser Compatibility

The Samsung 890 Series offers H-Browser through partnerships with certified system integrators providing guests with a premium interactive experience. Built on the HTML5 standard with Flash® support, H-Browser is a true Smart TV solution that features both free and video on demand (VOD) content. It is able to interface directly with the head end without the use of a set top box.

Mobile Device Integration AllShare™ Cast

Samsung AllShare™ Cast lets you seamlessly share content across your DLNA connected Samsung devices which includes WIDI without the need for a network cable or a connecting device. AllShare Cast allows screen mirroring and video streaming to enable seamless content sharing.

Specifications:


Samsung 55" 890 Series Edge-Lit Ultra-Thin LED Hospitality TV Specifications
Display
Backlight - Edge Lit LED - Edge Lit
Inch (Diagonal) 55"
HD/FHD FHD (1920 x 1080)
Video
Picture Engine 3D HyperReal Engine
Static Contrast Ratio 5000:1
Response Time 4.0ms
Viewing Angle (H/V) 178º / 178º
Brightness 450 nits
Micro Dimming Yes
Wide Color Enhancer Plus Yes
Auto Motion Plus 120/240Hz 240Hz
Film Mode Yes
Audio
Dolby® Dolby® Digital Plus / Dolby® Pulse
SRS / DNSe+ SRS TheaterSound HD™
DTS 2.0 + Digital Out™ DTS Premium Audio
3D Sound Yes
Speaker Type Down Firing + Full Range
Sound Output (RMS) 40W (10x2, woofer 10x2)
Variable Speaker Output 4W (Mono, 8Ω)
Features
Smart Hub Yes
Apps Yes
Photos, Clip & Music Yes
Samsung SMART View Yes (Clone View only)
Web Browser Yes
Hand Gesture Recognition Ready
Voice Recognition Yes
Samsung TV Apps supported Yes
Samsung 3D Yes
3D Converter Yes
Smart Phone Remote Support Yes
Allshare™ Play (Powered by DLNA) Yes
AllShare™ Cast (Screen Mirroring) Yes
ConnectShare™ (USB 2.0) Movie
Soft AP Yes
Wireless LAN Built-in Yes
BT HID Built-in Yes
USB HID Support Yes
Sound Share Yes
OSD Language English, Spanish, French
Digital Noise Filter Yes
HDMI 1.4 3D Auto Setting Yes
HDMI 1.4 A / Return Ch. Support Yes
Anynet+ (HDMI-CEC) Yes
BD Wise Plus Yes
Auto Channel Search Yes
Auto Power Off Yes
Auto Volume Leveler Yes
Caption (Subtitle) Yes
Wake-up Timer Yes
Game Mode Yes
Picture-In-Picture Yes
Sleep Timer Yes
Hospitality Features
Samsung LYNK™ DRM Yes
Pro:Idiom™ DRM Yes
Hospitality Plug & Play (Easy Set-up) Yes
Music Mode (Input: PC/AV/Component) Yes
Music Mode BackLight on/off Yes
RJ 12 / IR Pass Through Yes
Power on Status Setting Yes
Jack Pack Compatiblity (HD Media Hub) Yes
USB Cloning Yes
Bathroom Speaker Output Yes
Hotel Channel List Yes
Hotel Logo Display with Time Out Setting (BMP) Yes
Hotel Logo Display (Movie file) Yes
Welcome Message Yes
Auto Source Mode Yes
Energy Saving Mode (BLU control) Yes
Multi Code Remote Control Yes
Screwed Remote Battery Cover Yes
Alarm Key No
Pillow Speaker Compatibility Yes
Samsung LYNK™ SINC Compatibility Yes
H-Browser Compatibility Yes
Smoovie Compatibility Yes
Samsung LYNK™ REACH Server Compatibility Yes
Sound bar compatibility Yes
HDMI (Side/Rear) 3/0
USB (Side/Rear) 1/0
Component In (Y/Pb/Pr) (Side/Rear) 1/0
Composite In (AV) (Side/Rear) 1 (Common Use for Component Y)
Ethernet (LAN) (Side/Rear) 1/0
Digital Audio Out (Optical) (Side/Rear) 1/0
Audio Out (Mini Jack) (Side/Rear) 1/0
DVI Audio In (Mini Jack) (Side/Rear) 1/0
RF In (Terrestrial/Cable input) (Side/Rear) 1/0
RS232C (AV CONTROL) (Side/Rear) 1 (Common Use for RJP)
Variable Audio Out Yes
VOL-CTRL Yes
RJ12 Yes
RJ45 Yes
RJP (For Remote Jackpack) Yes
System
DTV Tuner ATSC / Clear QAM
Analog Tuner Yes
Design
Front Color Black
Stand Type Arch
Swivel (Left/Right) No
Dimension (WxHxD)
Set Size with Stand (mm) / ( Inches) 1224.2 x 741.9 x 310.3 /48.2" x 29.2" x 12.21"
Set Size without Stand (mm) / (Inches) 1224.2 x 707.2 x 34.9 /48.2" x 27.84" x 1.37"
Carton Dimensions
(H x W x L) (mm) / (Inches) 1350.0 x 205.0 x 820.0 / 53" x 8.0" x 32.3"
Weight
Set Weight with Stand (kg / lbs) 18.3 / 40.34
Set Weight without Stand (kg / lbs) 16.8 / 37
Packaging Weight
Gross weight (kg / lbs) 23.100 / 50.9
VESA Mounting
Dimensions (mm) 400 x 400
Screw Size M8
Power
Power Supply AC110-120V 50/60Hz
Multi Voltage AC110-220V
Power Consumption (Rated) (Watts) 178W
Power Consumption (Stand-by) (Watts) Under 0.5W
Power Consumption (Typical) (Watts) 61W
UPC
UPC 8806085688728
Eco
Eco Mark Energy Star v6.0
Eco Sensor Yes
Accessory
Remote Controller Model TM1390B + TM1240
Battery (for Remote Control) Yes
Vesa Wall Mount Support Yes
Slim Gender Cable 1 AV, 1 Component (AV share)
Power Cable Yes
Quick Install Guide Yes
Data Cable Yes

Compare:


Samsung 890 Series Hospitality TVs Comparison
Model Number HG46NB890XFXZA HG55NB890XFXZA HG65NB890XFXZA
Display
Backlight - Edge Lit LED - Edge Lit LED - Edge Lit LED - Edge Lit
Inch (Diagonal) 46" 55" 65"
HD/FHD FHD (1920 x 1080) FHD (1920 x 1080) FHD (1920 x 1080)
Video
Picture Engine 3D HyperReal Engine 3D HyperReal Engine 3D HyperReal Engine
Static Contrast Ratio 5000:1 5000:1 5500:1
Response Time 4.0ms 4.0ms 6.5ms
Viewing Angle (H/V) 178º / 178º 178º / 178º 178º / 178º
Brightness 450 nits 450 nits 450 nits
Micro Dimming Yes Yes Yes
Wide Color Enhancer Plus Yes Yes Yes
Auto Motion Plus 120/240Hz 240Hz 240Hz 240Hz
Film Mode Yes Yes Yes
Audio
Dolby® Dolby® Digital Plus / Dolby® Pulse Dolby® Digital Plus / Dolby® Pulse Dolby® Digital Plus / Dolby® Pulse
SRS / DNSe+ SRS TheaterSound HD™ SRS TheaterSound HD™ SRS TheaterSound HD™
DTS 2.0 + Digital Out™ DTS Premium Audio DTS Premium Audio DTS Premium Audio
3D Sound Yes Yes Yes
Speaker Type Down Firing + Full Range Down Firing + Full Range Down Firing + Full Range
Sound Output (RMS) 40W (10x2, woofer 10x2) 40W (10x2, woofer 10x2) 40W (10x2, woofer 10x2)
Variable Speaker Output 4W (Mono, 8Ω) 4W (Mono, 8Ω) 4W (Mono, 8Ω)
Features
Smart Hub Yes Yes Yes
Apps Yes Yes Yes
Photos, Clip & Music Yes Yes Yes
Samsung SMART View Yes (Clone View only) Yes (Clone View only) Yes (Clone View only)
Web Browser Yes Yes Yes
Hand Gesture Recognition Ready Ready Ready
Voice Recognition Yes Yes Yes
Samsung TV Apps supported Yes Yes Yes
Samsung 3D Yes Yes Yes
3D Converter Yes Yes Yes
Smart Phone Remote Support Yes Yes Yes
Allshare™ Play (Powered by DLNA) Yes Yes Yes
AllShare™ Cast (Screen Mirroring) Yes Yes Yes
ConnectShare™ (USB 2.0) Movie Movie Movie
Soft AP Yes Yes Yes
Wireless LAN Built-in Yes Yes Yes
BT HID Built-in Yes Yes Yes
USB HID Support Yes Yes Yes
Sound Share Yes Yes Yes
OSD Language English, Spanish, French English, Spanish, French English, Spanish, French
Digital Noise Filter Yes Yes Yes
HDMI 1.4 3D Auto Setting Yes Yes Yes
HDMI 1.4 A / Return Ch. Support Yes Yes Yes
Anynet+ (HDMI-CEC) Yes Yes Yes
BD Wise Plus Yes Yes Yes
Auto Channel Search Yes Yes Yes
Auto Power Off Yes Yes Yes
Auto Volume Leveler Yes Yes Yes
Caption (Subtitle) Yes Yes Yes
Wake-up Timer Yes Yes Yes
Game Mode Yes Yes Yes
Picture-In-Picture Yes Yes Yes
Sleep Timer Yes Yes Yes
Hospitality Features
Samsung LYNK™ DRM Yes Yes Yes
Pro:Idiom™ DRM Yes Yes Yes
Hospitality Plug & Play (Easy Set-up) Yes Yes Yes
Music Mode (Input: PC/AV/Component) Yes Yes Yes
Music Mode BackLight on/off Yes Yes Yes
RJ 12 / IR Pass Through Yes Yes Yes
Power on Status Setting Yes Yes Yes
Jack Pack Compatiblity (HD Media Hub) Yes Yes Yes
USB Cloning Yes Yes Yes
Bathroom Speaker Output Yes Yes Yes
Hotel Channel List Yes Yes Yes
Hotel Logo Display with Time Out Setting (BMP) Yes Yes Yes
Hotel Logo Display (Movie file) Yes Yes Yes
Welcome Message Yes Yes Yes
Auto Source Mode Yes Yes Yes
Energy Saving Mode (BLU control) Yes Yes Yes
Multi Code Remote Control Yes Yes Yes
Screwed Remote Battery Cover Yes Yes Yes
Alarm Key No No No
Pillow Speaker Compatibility Yes Yes Yes
Samsung LYNK™ SINC Compatibility Yes Yes Yes
H-Browser Compatibility Yes Yes Yes
Smoovie Compatibility Yes Yes Yes
Samsung LYNK™ REACH Server Compatibility Yes Yes Yes
Sound bar compatibility Yes Yes Yes
HDMI (Side/Rear) 3/0 3/0 3/0
USB (Side/Rear) 1/0 1/0 1/0
Component In (Y/Pb/Pr) (Side/Rear) 1/0 1/0 1/0
Composite In (AV) (Side/Rear) 1 (Common Use for Component Y) 1 (Common Use for Component Y) 1 (Common Use for Component Y)
Ethernet (LAN) (Side/Rear) 1/0 1/0 1/0
Digital Audio Out (Optical) (Side/Rear) 1/0 1/0 1/0
Audio Out (Mini Jack) (Side/Rear) 1/0 1/0 1/0
DVI Audio In (Mini Jack) (Side/Rear) 1/0 1/0 1/0
RF In (Terrestrial/Cable input) (Side/Rear) 1/0 1/0 1/0
RS232C (AV CONTROL) (Side/Rear) 1 (Common Use for RJP) 1 (Common Use for RJP) 1 (Common Use for RJP)
Variable Audio Out Yes Yes Yes
VOL-CTRL Yes Yes Yes
RJ12 Yes Yes Yes
RJ45 Yes Yes Yes
RJP (For Remote Jackpack) Yes Yes Yes
System
DTV Tuner ATSC / Clear QAM ATSC / Clear QAM ATSC / Clear QAM
Analog Tuner Yes Yes Yes
Design
Front Color Black Black Black
Stand Type Arch Arch Arch
Swivel (Left/Right) No No No
Dimension (WxHxD)
Set Size with Stand (mm) / ( Inches) 1032.7 x 634.3 x 257.7 / 40.66" x 29.97" x 10.15" 1224.2 x 741.9 x 310.3 /48.2" x 29.2" x 12.21" 1447.3 x 876 x 330.3 /57" x 34.5" x 13"
Set Size without Stand (mm) / (Inches) 1032.7 x 599.5 x 34.9 /40.7" x 23.6" x 1.37" 1224.2 x 707.2 x 34.9 /48.2" x 27.84" x 1.37" 1447.3 x 837.6 x 38.4 /57" x 33" x 1.37"
Carton Dimensions
(H x W x L) (mm) / (Inches) 1139.0 x 204.0 x 711.0 / 44.8" x 8.0" x 28" 1350.0 x 205.0 x 820.0 / 53" x 8.0" x 32.3" 1585.0 x 257.0 x 949.0 / 62.4" x 10.1" x 37.4"
Weight
Set Weight with Stand (kg / lbs) 14 / 31 18.3 / 40.34 26.9 / 59.3
Set Weight without Stand (kg / lbs) 12.8 / 28.2 16.8 / 37 24.6 / 54.2
Packaging Weight
Gross weight (kg / lbs) 16.300 / 35.9 23.100 / 50.9 34 / 75
VESA Mounting
Dimensions (mm) 200 x 200 400 x 400 400 x 400
Screw Size M8 M8 M8
Power
Power Supply AC110-120V 50/60Hz AC110-120V 50/60Hz AC110-120V 50/60Hz
Multi Voltage AC110-220V AC110-220V AC110-220V
Power Consumption (Rated) (Watts) 149W 178W 185W
Power Consumption (Stand-by) (Watts) Under 0.5W Under 0.5W Under 0.5W
Power Consumption (Typical) (Watts) 57W 61W 75W
UPC
UPC 8806085688704 8806085688728 8806085688735
Eco
Eco Mark Energy Star v6.0 Energy Star v6.0 Energy Star v6.0
Eco Sensor Yes Yes Yes
Accessory
Remote Controller Model TM1390B + TM1240 TM1390B + TM1240 TM1390B + TM1240
Battery (for Remote Control) Yes Yes Yes
Vesa Wall Mount Support Yes Yes Yes
Slim Gender Cable 1 AV, 1 Component (AV share) 1 AV, 1 Component (AV share) 1 AV, 1 Component (AV share)
Power Cable Yes Yes Yes
Quick Install Guide Yes Yes Yes
Data Cable Yes Yes Yes

Documentation:

Download the Samsung 890 Series Hospitality TVs Datasheet (.PDF)
