Samsung DM55E - DM-E Series 55" Slim Direct-Lit LED Display
Deliver an outstanding visual experience with Full HD resolution on the 55" screen.

Samsung DM55E - DM-E Series 55" Slim Direct-Lit LED Display

Samsung Products
Samsung Digital Signage
DM55E - DM-E Series 55" Slim Direct-Lit LED Display
#LH55DMEPLGA/GO
Our Price: $1,560.00

More pricing below, click here!

Overview:

Samsung's DM55E displays provide around the clock reliability to meet your business' 24/7 operating requirements, at a competitive price. Deliver an outstanding visual experience with Full HD resolution on the 55" screen, while a lightweight design ensures installation ease and a full range of connectivity inputs offer flexible content options.

  • Reliable 24/7 Operation and Enhanced System-on-Chip Performance with a Quad Core CPU
  • Sleek Industrial Design with a 9.5mm Bezel and Ultra-Slim 2.0" Chassis
  • Built-In Wi-Fi® for Expanded Connectivity
  • Transform Your Display with an Optional Touch Overlay for a PC-Less Touch Solution

Features

Reliable 24/7 Continuous Operation

Innovative Samsung cooling technologies allow your message to be displayed with highly reliable 24/7 continuous operation, so your business can meet around the clock operating requirements.

Enhanced System-on-Chip Performance with a Quad Core CPU

Powered by a System-on-Chip (SoC) semiconductor and quad core CPU with 8GB of storage, Samsung's SMART Signage Platform is an open and integrated player side media platform that provides a powerful, streamlined solution to reduce TCO for digital signage deployments, through savings in hardware, installation and operating costs.

Sleek Industrial Design

The 9.5mm bezel provides a sleek, elegant look that can be polished with optional customizable bezel trim kits in matte black or white. And the stylish, ultra-slim 2.0" chassis helps simplify installation while meeting ADA compliance requirements.

Slim Direct-Lit LED Backlight

Achieve sharp, detail-rich images and crisp, legible type with this slim direct-lit display featuring 1920 x 1080 Full HD resolution with 450 nits brightness and a 5,000:1 contrast ratio.

Optional Touch Overlay

The optional touch overlay accessory delivers a cost effective, PC-less touch solution that transforms your display into an interactive whiteboard with up to 10 simultaneous touchpoints. Create more collaborative presentations or a dynamic customer experience with tangible results for your business.

Built-In Wi-Fi®

Enjoy the versatility of expanded connectivity to mobile devices, from easy media sharing and screen control to simple content mirroring from a tablet or mobile phone to your display.

MagicInfo S3 Digital Signage Software

Create playlists, set playback schedules and publish content directly to the display with this software. Most traditional file formats are supported including RSS feed and live web pages.

Specifications:


Samsung DM55E - DM-E Series 55" Slim Direct-Lit LED Display Specifications
Display
Screen Size 55"
Panel Technology 60Hz Slim D-LED BLU
Resolution 1920x1080 (16:9)
Brightness 450 nits
Contrast Ratio 5000:1
Viewing Angle (Horizontal/Vertical) 178° / 178°
Orientation Landscape / Portrait
Response Time (G-to-G) 8ms
Connectivity
Input VGA (D-Sub 15 Pin), DVI-D(HDMI Common), DisplayPort 1.2, HDMI1, HDMI2 (thru DVI-D Input, Adapter Not Included), Component/Composite, Stereo Mini Jack, USB 2.0 x 1
Output DisplayPort 1.2 (Loop-Out), Stereo Mini Jack
External Control RS232C (In/Out) thru Stereo Jack, RJ45
External Sensor IR, Ambient Light
Power
Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption (Typical/Max) 65W / 176W
Power Consumption (Standby) < 0.5W
Environmental Conditions
Operating Temperature 0°C - 40°C
Operating Humidity 10%~80%
Features
  Slim and Light LFD with Built-in MagicInfo Player S3
Special Hardware Super Clear Coating, Temperature Sensor, Pivot Display, Button Lock, Clock Battery (80hrs Clock Keeping), Built in Speaker (10Wx1), Wi-Fi Module Embedded, SD Card Slot
Software Magic Clone (to USB), Auto Source Switching & Recovery, RS232C/RJ45 MDC,Plug and Play (DDC2B), PIP/PBP, Image Rotation, Built-in MagicInfo S3, Firmware Update by Network, Predefined Template for Vertical Usage, Multi Channel, Mobile Control, Event Schedule, Backup Player, PC-less Touch
Tuner Yes
SMART Signage Platform Compliant Yes
Internal Media Player Cortex-A9 1GHz Quad Core, 1.5GB DDR3, 8GB Storage, USB 2.0, Samsung Proprietary OS (VDLinux)
VESA Standard Wall Mount Interface 400 x 400mm
24/7 Operation Yes
Dimensions
Product Dimensions (without stand) 48.4" x 27.8" x 2.0"
Packaging Dimensions 53.1" x 31.9" x 5.8"
Bezel Width 9.5mm (Top, Left), 15.0mm (Right, Bottom)
Weight
Product Weight 34 lbs.
Shipping Weight 43 lbs.
Service
Standard Warranty 3 Years On-Site (Parts / Labor / Backlight)
Accessories
Included Quick Setup Guide, Warranty Card, D-Sub Cable, Power Cord, Remote Controller, Batteries
Optional Mount WMN4270SD, WMN250MD
Optional Stand STN-L4655E
External Media Player SBB-DA, SBB-DI, SBB-B32D
Optional Touch Overlay CY-TD55LDAH
Optional Bezel Trim Kit CY-BD55BD (Matte Black), CY-BD55WD (White)
Green Management
Emission Standard EMC
ENERGY STAR® 6.0 Compliant Yes
RoHS Compliant Yes
Packaging Recyclability Packing Materials Recyclable

Compare:


Samsung DM55E - DM-E Series 55" Slim Direct-Lit LED Display
Model Number DM32E DM40E DM48E DM55E
Display
Screen Size 32" 40" 48" 55"
Panel Technology 60Hz Slim D-LED BLU 60Hz Slim D-LED BLU 60Hz Slim D-LED BLU 60Hz Slim D-LED BLU
Resolution 1920x1080 (16:9) 1920x1080 (16:9) 1920x1080 (16:9) 1920x1080 (16:9)
Brightness 400 nits 450 nits 450 nits 450 nits
Contrast Ratio 5000:1 5000:1 5000:1 5000:1
Viewing Angle (Horizontal/Vertical) 178° / 178° 178° / 178° 178° / 178° 178° / 178°
Orientation Landscape / Portrait Landscape / Portrait Landscape / Portrait Landscape / Portrait
Response Time (G-to-G) 8ms 8ms 8ms 8ms
Connectivity
Input VGA (D-Sub 15 Pin), DVI-D (HDMI Common), HDMI1, HDMI2 (thru DVI-D Input, Adapter Not Included), Component/Composite, Stereo Mini Jack, USB 2.0 x 1 VGA (D-Sub 15 Pin), DVI-D(HDMI Common), DisplayPort 1.2, HDMI1, HDMI2 (thru DVI-D Input, Adapter Not Included), Component/Composite, Stereo Mini Jack, USB 2.0 x 1 VGA (D-Sub 15 Pin), DVI-D (HDMI Common), DisplayPort 1.2, HDMI1, HDMI2 (thru DVI-D Input, Adapter Not Included), Component/Composite, Stereo Mini Jack, USB 2.0 x 1 VGA (D-Sub 15 Pin), DVI-D(HDMI Common), DisplayPort 1.2, HDMI1, HDMI2 (thru DVI-D Input, Adapter Not Included), Component/Composite, Stereo Mini Jack, USB 2.0 x 1
Output Stereo Mini Jack DisplayPort 1.2 (Loop-Out), Stereo Mini Jack DisplayPort 1.2 (Loop-Out), Stereo Mini Jack DisplayPort 1.2 (Loop-Out), Stereo Mini Jack
External Control RS232C (In/Out) thru Stereo Jack, RJ45 RS232C (In/Out) thru Stereo Jack, RJ45 RS232C (In/Out) thru Stereo Jack, RJ45 RS232C (In/Out) thru Stereo Jack, RJ45
External Sensor IR, Ambient Light IR, Ambient Light IR, Ambient Light IR, Ambient Light
Power
Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption (Typical/Max) 30W / 77W 44W / 121W 50W / 132W 65W / 176W
Power Consumption (Standby) < 0.5W < 0.5W < 0.5W < 0.5W
Environmental Conditions
Operating Temperature 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C
Operating Humidity 10%~80% 10%~80% 10%~80% 10%~80%
Features
  Slim and Light LFD with Built-in MagicInfo Player S3 Slim and Light LFD with Built-in MagicInfo Player S3 Slim and Light LFD with Built-in MagicInfo Player S3 Slim and Light LFD with Built-in MagicInfo Player S3
Special Hardware Super Clear Coating, Temperature Sensor, Pivot Display, Button Lock, Clock Battery (80hrs Clock Keeping), Built in Speaker (10Wx1), Wi-Fi Module Embedded, SD Card Slot Super Clear Coating, Temperature Sensor, Pivot Display, Button Lock, Clock Battery (80hrs Clock Keeping), Built in Speaker (10Wx1), Wi-Fi Module Embedded, SD Card Slot Super Clear Coating, Temperature Sensor, Pivot Display, Button Lock, Clock Battery (80hrs Clock Keeping), Built in Speaker (10Wx1), Wi-Fi Module Embedded, SD Card Slot Super Clear Coating, Temperature Sensor, Pivot Display, Button Lock, Clock Battery (80hrs Clock Keeping), Built in Speaker (10Wx1), Wi-Fi Module Embedded, SD Card Slot
Software Magic Clone (to USB), Auto Source Switching & Recovery, RS232C/RJ45 MDC, Plug and Play (DDC2B), PIP/PBP, Image Rotation, Built-in MagicInfo S3, Firmware Update by Network, Predefined Template for Vertical Usage, Multi Channel, Mobile Control, Event Schedule, Backup Player, PC-less Touch Magic Clone (to USB), Auto Source Switching & Recovery, RS232C/RJ45 MDC,Plug and Play (DDC2B), PIP/PBP, Image Rotation, Built-in MagicInfo S3, Firmware Update by Network, Predefined Template for Vertical Usage, Multi Channel, Mobile Control, Event Schedule, Backup Player, PC-less Touch Magic Clone (to USB), Auto Source Switching & Recovery, RS232C/RJ45 MDC,Plug and Play (DDC2B), PIP/PBP, Image Rotation, Built-in MagicInfo S3, Firmware Update by Network, Predefined Template for Vertical Usage, Multi Channel, Mobile Control, Event Schedule, Backup Player, PC-less Touch Magic Clone (to USB), Auto Source Switching & Recovery, RS232C/RJ45 MDC,Plug and Play (DDC2B), PIP/PBP, Image Rotation, Built-in MagicInfo S3, Firmware Update by Network, Predefined Template for Vertical Usage, Multi Channel, Mobile Control, Event Schedule, Backup Player, PC-less Touch
Tuner Yes Yes Yes Yes
SMART Signage Platform Compliant Yes Yes Yes Yes
Internal Media Player Cortex-A9 1GHz Quad Core, 1.5GB DDR3, 8GB Storage, USB 2.0, Samsung Proprietary OS (VDLinux) Cortex-A9 1GHz Quad Core, 1.5GB DDR3, 8GB Storage, USB 2.0, Samsung Proprietary OS (VDLinux) Cortex-A9 1GHz Quad Core, 1.5GB DDR3, 8GB Storage, USB 2.0, Samsung Proprietary OS (VDLinux) Cortex-A9 1GHz Quad Core, 1.5GB DDR3, 8GB Storage, USB 2.0, Samsung Proprietary OS (VDLinux)
VESA Standard Wall Mount Interface 200 x 200mm 200 x 200mm 400 x 400mm 400 x 400mm
24/7 Operation Yes Yes Yes Yes
Dimensions
Product Dimensions (without stand) 28.4" x 16.5" x 2.0" 35.7" x 20.7" x 2.0" 42.3" x 24.4" x 2.0" 48.4" x 27.8" x 2.0"
Packaging Dimensions 32.1" x 19.3" x 5.2" 39.8" x 23.8" x 5.4" 46.7" x 28.1" x 5.8" 53.1" x 31.9" x 5.8"
Bezel Width 10.5mm (Top, Left), 15.0mm (Right, Bottom) 9.5mm (Top, Left), 15.0mm (Right, Bottom) 9.5mm (Top, Left), 15.0mm (Right, Bottom) 9.5mm (Top, Left), 15.0mm (Right, Bottom)
Weight
Product Weight 10.7 lbs. 16.6 lbs. 24.5 lbs. 34 lbs.
Shipping Weight 13 lbs. 20.1 lbs. 30.9 lbs. 43 lbs.
Service
Standard Warranty 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight)
Accessories
Included Quick Setup Guide, Warranty Card, D-Sub Cable, Power Cord, Remote Controller, Batteries Quick Setup Guide, Warranty Card, D-Sub Cable, Power Cord, Remote Controller, Batteries Quick Setup Guide, Warranty Card, D-Sub Cable, Power Cord, Remote Controller, Batteries Quick Setup Guide, Warranty Card, D-Sub Cable, Power Cord, Remote Controller, Batteries
Optional Mount WMN4070SD, WMN250MD WMN4070SD, WMN250MD WMN4270SD, WMN250MD WMN4270SD, WMN250MD
Optional Stand STN-L3240E STN-L3240E STN-L4655E STN-L4655E
External Media Player SBB-DA, SBB-DI, SBB-B32D (Not Attachable) SBB-DA, SBB-DI, SBB-B32D SBB-DA, SBB-DI, SBB-B32D SBB-DA, SBB-DI, SBB-B32D
Optional Touch Overlay CY-TD32LDAH CY-TD40LDAH CY-TD48LDAH CY-TD55LDAH
Optional Bezel Trim Kit CY-BD32BD (Matte Black), CY-BD32WD (White) CY-BD40BD (Matte Black), CY-BD40WD (White) CY-BD48BD (Matte Black), CY-BD48WD (White) CY-BD55BD (Matte Black), CY-BD55WD (White)
Green Management
Emission Standard EMC EMC EMC EMC
ENERGY STAR® 6.0 Compliant Yes Yes Yes Yes
RoHS Compliant Yes Yes Yes Yes
Packaging Recyclability Packing Materials Recyclable Packing Materials Recyclable Packing Materials Recyclable Packing Materials Recyclable
