Samsung DH40D - DH-D Series 40" Slim Direct-Lit LED Display
Powerful Messaging, Anytime, Anywhere.

Samsung DH40D - DH-D Series 40" Slim Direct-Lit LED Display

This product is no longer available, replaced by the DH40E 40" Slim Direct-Lit LED Display

Overview:

Samsung's DH40D is a slim, sleek and light 40" display designed to better inform and inspire your customers. It is capable of either landscape or portrait orientation, and the quad-core processing can easily display the most demanding graphics. 700 nits brightness allows you to communicate your message even in bright areas, and with innovative cooling technologies, you can enjoy 24/7 dependability.

  • Reliable 24/7 Continuous Operation
  • High Def with High 700-Nit Brightness
  • Enhanced System-on-Chip (SoC) Performance with Quad-Core CPU
  • New Industrial Design with Thin Bezel

Features

Reliable 24/7 Continuous Operation

Samsung DH-D Series commercial displays are designed from the chassis up to deliver the highest quality image with exceptional reliability, even during 24/7 continuous operation.

High Def with High 700-Nit Brightness

Experience sharp, stunning images with 1920 x 1080 Full HD resolution. And with 700-nit brightness, they’re visible even in brightly-lit environments.

Enhanced SoC Performance with Quad-Core

Powered by a System-on-Chip (SoC) semiconductor and quad-core CPU, Samsung’s SMART Signage Platform (SSP) reduces TCO for digital signage deployments, providing savings in hardware, installation and operating costs.

New Industrial Design with Thin Bezel

A sleek, stylish new look features a 9.5mm bezel. And the bezel color is customizable, to better fit your environment.

Ultra-Slim 2.0" Chassis

The stylishly thin chassis creates an elegant look and helps simplify installation, while meeting ADA compliance requirements.

Built-In Wi-Fi® and AllShare® Cast

Wi-Fi control of content allows you to eliminate LAN cables. Using AllShare Cast over a Wi-Fi connection enables simple content mirroring from a tablet or mobile phone to your display.

Optional Touch Overlay

The PC-less touch solution uses an embedded SoC without the need for an external PC. Add an optional IR touch overlay accessory to enable up to 10 simultaneous touch points, transforming your display into an interactive whiteboard.

Specifications:


Samsung DH40D - DH-D Series 40" Slim Direct-Lit LED Display Specifications
Display
Screen Size 40"
Panel Technology 60Hz Slim D-LED BLU
Resolution 1920 x 1080 (16:9)
Brightness 700 nits
Contrast Ratio 5000:1
Viewing Angle (Horizontal/Vertical) 178° / 178°
Orientation Landscape / Portrait
Response Time (G-to-G) 8ms
Connectivity
Input Video: VGA (D-Sub 15 Pin), DVI-D, DisplayPort 1.2, Component/Composite, HDMI, Audio: Stereo Mini Jack
Output Video: DisplayPort 1.2 (Loop-Out), Audio: Stereo Mini Jack
External Control RS232C (In/Out) thru Stereo Jack, RJ45
External Control IR, Ambient Light
Power
Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption (Typical/Max) 58W / 135W
Power Consumption (Standby) < 0.5W
Environmental Conditions
Operating Temperature 0°C - 40°C
Operating Humidity 10%~80%
Features
Special Hardware Super Clear Coating, Temperature Sensor, Videowall (15x15), Pivot Display, Clock Battery (80hrs Clock Keeping), Built in Speaker, Wi-Fi Module Embedded, Allshare Screen Mirroring, SD Card Slot
Software Magic Clone (to USB), Auto Source Switching & Recovery, Lamp Error Detection, RS232C/RJ45 MDC,Plug and Play (DDC2B), PIP/PBP, Image Rotation, Button Lock, DP 1.2 Digital Daisy Chain (Supporting 2x2 UHD Resolution, HDCP Support), Smart Scheduling, Smart F/W update, Built In MagicInfo Player S2, Firmware Update by Network, LFD New Home Screen, PC-less VideoWall, Predefined Template for Vertical Usage, Multi Channel, Mobile Control, Event Schedule, Backup Player, PC-less Touch
Tuner Yes
SMART Signage Platform Compliant Yes
Internal Media Player Cortex-A9 1Ghz Quad Core, 1.5GB DDR3, 8GB FDM, USB 2.0, Linux OS
VESA Standard Wall Mount Interface 200 x 200mm
24/7 Operation Yes
Dimensions
Product Dimensions (without stand) 35.7" x 20.7" x 2"
Packaging Dimensions 39.4" x 23" x 5"
Bezel Width 9.5mm (Top/Side), 15.0mm (Bottom)
Weight
Product Weight 16.6 lbs.
Shipping Weight 20.1 lbs.
Service
Standard Warranty 3 Years On-Site (Parts / Labor / Backlight)
Accessories
Included Quick Setup Guide, Warranty Card, D-Sub cable, Power Cord, Remote Controller, Batteries, RS232C(IN) adapter, Cover-Jack, Screw (M3L8, 1EA), (M4L8, 4EA)
Optional Mount WMN4070SD, WMN250MD
Optional Stand STN-L4055AD, STN-L3240E
Optional Touch Overlay CY-TD40
Optional Media Player PIM-BD7, PIM-BQ7P
Optional HDBase-T Receiver PIM-HDBT
Green Management
Emission Standard EMC
ENERGY STAR® 6.0 Compliant Yes
RoHS Compliant Yes
Packaging Recyclability Packing Materials Recyclable
Connectivity
  1. RS232C In
  2. RS232C Out
  3. IR/Ambient Sensor In
  4. Audio In
  5. Audio Out
  6. SD Card Slot
  7. USB
  8. DVI In
  9. DisplayPort In
  10. HDMI In
  11. VGA In
  12. Display Port Out
  13. Antenna In
  14. AV In
  15. IR Out
  16. RJ45 In
Connectivity

Compare:


Samsung DH-D Series Commercial LED LCD Displays Comparison
Model Number DH40D DH48D DH55D
Display
Screen Size 40" 48" 55"
Panel Technology 60Hz Slim D-LED BLU 60Hz Slim D-LED BLU 120Hz Slim D-LED BLU
Resolution 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9)
Brightness 700 nits 700 nits 700 nits
Contrast Ratio 5000:1 5000:1 5000:1
Viewing Angle (Horizontal/Vertical) 178° / 178° 178° / 178° 178° / 178°
Orientation Landscape / Portrait Landscape / Portrait Landscape / Portrait
Response Time (G-to-G) 8ms 8ms 8ms
Connectivity
Input Video: VGA (D-Sub 15 Pin), DVI-D, DisplayPort 1.2, Component/Composite, HDMI, Audio: Stereo Mini Jack Video: VGA (D-Sub 15 Pin), DVI-D, DisplayPort 1.2, Component/Composite, HDMI, Audio: Stereo Mini Jack Video: VGA (D-Sub 15 Pin), DVI-D, DisplayPort 1.2, Component/Composite, HDMI, Audio: Stereo Mini Jack
Output Video: DisplayPort 1.2 (Loop-Out), Audio: Stereo Mini Jack Video: DisplayPort 1.2 (Loop-Out), Audio: Stereo Mini Jack Video: DisplayPort 1.2 (Loop-Out), Audio: Stereo Mini Jack
External Control RS232C (In/Out) thru Stereo Jack, RJ45 RS232C (In/Out) thru Stereo Jack, RJ45 RS232C (In/Out) thru Stereo Jack, RJ45
External Control IR, Ambient Light IR, Ambient Light IR, Ambient Light
Power
Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption (Typical/Max) 58W / 135W 66W / 145W 86W / 175W
Power Consumption (Standby) < 0.5W < 0.5W < 0.5W
Environmental Conditions
Operating Temperature 0°C - 40°C 0°C - 40°C 0°C - 40°C
Operating Humidity 10%~80% 10%~80% 10%~80%
Features
Special Hardware Super Clear Coating, Temperature Sensor, Videowall (15x15), Pivot Display, Clock Battery (80hrs Clock Keeping), Built in Speaker, Wi-Fi Module Embedded, Allshare Screen Mirroring, SD Card Slot Super Clear Coating, Temperature Sensor, Videowall (15x15), Pivot Display, Clock Battery (80hrs Clock Keeping), Built in Speaker, Wi-Fi Module Embedded, Allshare Screen Mirroring, SD Card Slot Super Clear Coating, Temperature Sensor, Videowall (15x15), Pivot Display, Clock Battery (80hrs Clock Keeping), Built in Speaker, Wi-Fi Module Embedded, Allshare Screen Mirroring, SD Card Slot
Software Magic Clone (to USB), Auto Source Switching & Recovery, Lamp Error Detection, RS232C/RJ45 MDC,Plug and Play (DDC2B), PIP/PBP, Image Rotation, Button Lock, DP 1.2 Digital Daisy Chain (Supporting 2x2 UHD Resolution, HDCP Support), Smart Scheduling, Smart F/W update, Built In MagicInfo Player S2, Firmware Update by Network, LFD New Home Screen, PC-less VideoWall, Predefined Template for Vertical Usage, Multi Channel, Mobile Control, Event Schedule, Backup Player, PC-less Touch Magic Clone (to USB), Auto Source Switching & Recovery, Lamp Error Detection, RS232C/RJ45 MDC, Plug and Play (DDC2B), PIP/PBP, Image Rotation, Button Lock, DP 1.2 Digital Daisy Chain(Supporting 2x2 UHD Resolution, HDCP Support), Smart Scheduling, Smart F/W update, Built In MagicInfo Player S2, Firmware Update by Network, LFD New Home Screen, PC-less VideoWall, Predefined Template for Vertical Usage, Multi Channel, Mobile Control, Event Schedule, Backup Player, PC-less Touch Magic Clone (to USB), Auto Source Switching & Recovery, Lamp Error Detection, RS232C/RJ45 MDC, Plug and Play (DDC2B), PIP/PBP, Image Rotation, Button Lock, DP 1.2 Digital Daisy Chain(Supporting 2x2 UHD Resolution, HDCP Support), Smart Scheduling, Smart F/W update, Built In MagicInfo Player S2, Firmware Update by Network, LFD New Home Screen, PC-less VideoWall, Predefined Template for Vertical Usage, Multi Channel, Mobile Control, Event Schedule, Backup Player, PC-less Touch
Tuner Yes Yes Yes
SMART Signage Platform Compliant Yes Yes Yes
Internal Media Player Cortex-A9 1Ghz Quad Core, 1.5GB DDR3, 8GB FDM, USB 2.0, Linux OS Cortex-A9 1Ghz Quad Core, 1.5GB DDR3, 8GB FDM, USB 2.0, Linux OS Cortex-A9 1Ghz Quad Core, 1.5GB DDR3, 8GB FDM, USB 2.0, Linux OS
VESA Standard Wall Mount Interface 200 x 200mm 400 x 400mm 400 x 400mm
24/7 Operation Yes Yes Yes
Dimensions
Product Dimensions (without stand) 35.7" x 20.7" x 2" 42.3" x 24.4" x 2.0" 48.4" x 27.8" x 2.0"
Packaging Dimensions 39.4" x 23" x 5" 46.7" x 28.1" x 5.8" 53.1" x 31.9" x 5.8"
Bezel Width 9.5mm (Top/Side), 15.0mm (Bottom) 9.5mm (Top/Side), 15.0mm (Bottom) 9.5mm (Top/Side), 15.0mm (Bottom)
Weight
Product Weight 16.6 lbs. 24.5 lbs 34 lbs.
Shipping Weight 20.1 lbs. 30.9 lbs. 43 lbs
Service
Standard Warranty 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight)
Accessories
Included Quick Setup Guide, Warranty Card, D-Sub cable, Power Cord, Remote Controller, Batteries, RS232C(IN) adapter, Cover-Jack, Screw (M3L8, 1EA), (M4L8, 4EA) Quick Setup Guide, Warranty Card, D-Sub cable, Power Cord, Remote Controller, Batteries, RS232C(IN) adapter, Cover-Jack, Screw (M3L8, 1EA), (M4L8, 4EA) Quick Setup Guide, Warranty Card, D-Sub cable, Power Cord, Remote Controller, Batteries, RS232C(IN) adapter, Cover-Jack, Screw (M3L8, 1EA), (M4L8, 4EA)
Optional Mount WMN4070SD, WMN250MD WMN4270SD, WMN250MD WMN4270SD, WMN250MD
Optional Stand STN-L4055AD, STN-L3240E STN-L4055AD, STN-L4655E STN-L4055AD, STN-L4655E
Optional Touch Overlay CY-TD40 CY-TD48 CY-TD55
Optional Media Player PIM-BD7, PIM-BQ7P PIM-BD7, PIM-BQ7P PIM-BD7, PIM-BQ7P
Optional HDBase-T Receiver PIM-HDBT PIM-HDBT PIM-HDBT
Green Management
Emission Standard EMC EMC EMC
ENERGY STAR® 6.0 Compliant Yes Yes Yes
RoHS Compliant Yes Yes Yes
Packaging Recyclability Packing Materials Recyclable Packing Materials Recyclable Packing Materials Recyclable
Connectivity
  1. RS232C In
  2. RS232C Out
  3. IR/Ambient Sensor In
  4. Audio In
  5. Audio Out
  6. SD Card Slot
  7. USB
  8. DVI In
  9. DisplayPort In
  10. HDMI In
  11. VGA In
  12. Display Port Out
  13. Antenna In
  14. AV In
  15. IR Out
  16. RJ45 In
Connectivity
